Product Details
MECO 3½ & 4½ DIGIT LCD MODULES - PROFESSIONAL SERIES, 3½ DIGIT LED MODULES - PROFESSIONAL SERIES (GM135 LED)
₹334.4
₹380.00
12%
Sold By :
Delivery duration : * 8 to 10 Days
In Stock
(24 items left)
Quantity:
Size : 0-199.9mV to199.9 V Price : 380
Size : 199.9 micro A to 199.9 mA Price : 379
Return Policy:
Thank you for purchasing our products/services. We value your trust and assure you of the best product/services at all times. As our customer, when you are buying our product or service, you agree to our refund policy. Once you have made a purchase on our platform. View details
TECHNICAL DATAS
Model - GM135 LED
Measuring Method - 3½ Digit-Dual Slope A/D Conversion 4½ Digit-Successive Integration A/D Conversion
Sampling Rate - 2.5 sample /sec
Display Type -14.2 mm/0.56" Digit Height Red LED
Maximum display typ -1999 counts for 3½ Digit Meters 19999 counts for 4½ Digit Meters
Resolution -0.001 to 1 count for 3½ depending on the range 0.0001 to 1 count for 4½ depending on the range
Polarity Indication - “ - ” is indicated for negative input
Decimal Selection - Field Selectable
Over Range Ind. - “ 1 ” or “ -1 ”
Maximum Overload - Voltage : 1.2 times continuous Current : 2 times continuous
VA Burden (Typical) -Auxiliary : < 20mVA (LCD) & <1VA (LED) Voltage : < 0.1VA, Current : < 0.25VAFrequency Response - 40 - 400Hz
Environment -Calibration : 27OC±5OC, Operating : 0 to 50OC, RH < 70% Storage : -10 to 60OC, RH < 70%
Mounting Bezel - Elegant Black ABS Bezel with 4 fixing screws and necessary hardware
Connectors - PCB Edge Connector (Optional)
Display Stability - Within ± 2 Digits
Faceplate - Red Antiglare Lens - LED
FEATURES
- 3½ Digit-Dual Slope A/D Conversion
- 4½ Digit-Successive Integration A/D Conversion
- 1999 counts for 3½ Digit Meters
- 19999 counts for 4½ Digit Meters
- Field Selection of Decimal Point
- High Accuracy Across the Entire Range
- Face plate of Red Antiglare Lens - LED
WARRANTY :- 1 YEAR
